Xiris

Infrared Camera

Model XIR-1800

System overview
- Combining an impressive HDR feature of over 120dB in the Short-Wave Infrared (SWIR) spectrum
- The XIR-1800 thermal camera provides enhanced imaging for metal joining processes beyond what can be seen with standard thermal or visible light cameras.
- Offering calibrated thermal readings (350~1800°C) for the main melting and transition temperatures of most metals, it ensures additional quality assurance and improved process control.
- Moreover, it excels in capturing welding fumes better than CMOS or NIR thermal cameras.

Video

Key functionsand features

  • It provides low sensitivity to emissivity changes, a crucial factor in thermal imaging of metal.
  • Capable of high-speed imaging (100-1000fps) and temperature measurement, it seamlessly integrates with other Xiris welding cameras and WeldMic™.
  • Real-time data capture, output via OPC-UA, offline recording, and analysis and review are all possible.
